Replacement Cooling Unit for Vinotheque Wine Cabinets
This Model Is Only Available As The Replacement Unit.
NOTE: WhisperKOOL 2500 Cabinet System can be used as a replacement for older models of WhisperKOOL cooling units, such as 1000, 1100, 1200, and 2300, without any modifications needed. However, if you wish to replace other brands of cooling units, modifications to the cabinet may be required.
The WhisperKOOL 2500 Cabinet System is a direct replacement cooling unit for Vinotheque wine cabinets previously equipped with WhisperKOOL 1000, 1100, 1200, or 2300 systems. It is designed exclusively for insulated wine cabinets and is not suitable for open wine rooms or custom-built enclosures.
Is the WhisperKOOL 2500 the Correct Replacement for Your Cabinet?
The 2500 Cabinet System is appropriate if:
- You own a Vinotheque wine cabinet.
- Your current cooling unit is a WhisperKOOL 1000, 1100, 1200, or 2300.
- You can provide the serial number of your existing unit or photos of your cabinet.
- The exhaust environment does not exceed 85°F.
This unit is sold strictly as a replacement system for existing cabinet installations.
Do Not Purchase This Unit If:
- You are installing into a custom-built wine room.
- You are attempting to cool an open cellar space.
- Your cabinet is not a Vinotheque cabinet.
- Your exhaust area regularly exceeds 85°F.
- You cannot verify compatibility before shipment.
Improper installation or incorrect application may result in insufficient cooling performance or reduced system lifespan.
Replacement Compatibility
The WhisperKOOL 2500 directly replaces the following cabinet cooling units without structural modification:
| Existing Model |
Direct Replacement |
Cabinet Modifications Required |
| WhisperKOOL 1000 |
Yes |
No |
| WhisperKOOL 1100 |
Yes |
No |
| WhisperKOOL 1200 |
Yes |
No |
| WhisperKOOL 2300 |
Yes |
No |
| Other Brands |
Case-by-case |
Possible |
Before shipment, one of the following is required:
- Serial number of your current WhisperKOOL cabinet system
OR
- Clear photos of your Vinotheque cabinet and installed unit
Orders cannot ship without compatibility verification.
Cooling Performance & Operating Limits
Designed for Insulated Wine Cabinets
The 2500 Cabinet System is engineered for factory-built, insulated wine cabinets where airflow and insulation parameters are predefined. It is not a room-cooling system.
30°F Temperature Differential Explained
The system is designed to maintain proper cabinet temperature when the exhaust environment does not exceed 85°F.
This means:
- If the exhaust space is 85°F, the unit can maintain cabinet temperatures approximately 30°F lower.
- If exhaust temperatures exceed 85°F, cooling capacity decreases and compressor stress increases.
Proper ventilation around the exhaust side of the cabinet is essential for long-term reliability.
Platinum Series Digital Controller
Advanced System Protection Technology
The WhisperKOOL 2500 includes a Platinum Series digital controller designed to stabilize cabinet conditions and protect mechanical components.
Controller features include:
- Digital temperature display
- Adjustable humidity control
- Energy-saving mode
- Quick chill mode
- Anti-frost function
- Liquid temperature-measuring bottle probe
Why the Bottle Probe Matters
The bottle probe measures liquid temperature rather than air temperature, reducing compressor short cycling and providing more stable wine storage conditions.
Cabinet Housing & Construction
The 2500 Cabinet System includes durable structural components designed for cabinet integration:
- Galvanized steel base
- 20-gauge embossed galvanized steel cabinet
- Hinged access panel for servicing
- Rain trough beneath hinge to manage incidental moisture
- 45° front louvers for airflow direction
- Condenser screen with high-temperature baked-on clear lacquer coating
- Wind safety latch
- Necessary fasteners included
- Shipped knocked down for convenient warehousing and assembly
These features support durability, moisture management, and service access within cabinet installations.
Electrical & Installation Requirements
- Voltage: 115V
- Starting Amps: 17
- Running Amps: 3
- Refrigerant: R-134a
- Certification: UL Listed
- Installation Type: Replacement inside existing Vinotheque cabinet
A dedicated electrical circuit is recommended.
The unit must be installed within manufacturer-specified environmental limits.
Technical Specifications
| Specification |
Details |
| Model |
2500 Cabinet System |
| Evaporator Dimensions |
20"W x 10.25"H x 14"D |
| Weight |
55 lbs |
| Refrigerant |
R-134a |
| Voltage |
115V |
| Starting Amps |
17 |
| Running Amps |
3 |
| Temperature Differential |
30°F |
| Maximum Exhaust Environment |
85°F |
| Thermostat |
Digital Control Display |
| Warranty |
2-Year Limited / 5-Year Compressor |
| Compliance |
UL Listed |
Manuals for WhisperKOOL® Wine Cellar Cabinet System 2500:
Warranty
- Two-Year Limited Warranty
- Five-Year Compressor Warranty
Warranty coverage requires installation within approved environmental and application conditions.
Need Help Confirming Fitment?
If you are unsure whether the WhisperKOOL 2500 is the correct replacement for your cabinet, contact our team before ordering. We will help verify compatibility prior to shipment.
